| Model | UPL5545TC | UPL5580TC | UP5030 |
| Machine Dimension L×W×H (mm) | 1680×975×1500 | 2430×1565×1400 | 1672×770×1560 |
| Tunnel Dimension L×W×H (mm) | / | / | 1000×500×300 |
| Max Packing Size L×W×H (mm) | Unlimited | Unlimited | 400×250x150 |
| W+H (mm) | ≤430 | ≤750 | / |
| Cross Sealing L (mm) | 450 | 800 | / |
|
Packing Speed（pcs/min） Conveyor Speed（m/min） |
20-40 | 20-40 | 0-15 |
| Net Weight (kg) | 290 | 675 | 360 |
| Power (kw) | 1.8 | 2.2 | 12 |
| Power Supply |
3PH 220V/380V 50/60Hz |
3PH 220V/380V 50/60Hz |
3PH 220V/380V 50/60Hz |
| Air Pressure (kg/cm2) | 6-8 | 6-8 | / |
