Theoretical Output
2 cavities
4 cavities |
1700-1800pcs/hr 3200-3400pcs/hr |
| Product Capacity | 0.1-2L |
| Diameter of Bottle Mouth | 15-38mm |
| Diameter of Bottle Body | 40-90mm |
| Height of Bottle | 280mm |
| Clamping Stroke | 150mm |
| Clamping Force | 200ton |
| Total Power | 30KW |
| Working Pressure | 0.8-1.0Mpa |
| Blowing Pressure | 2.2-3.0Mpa |
| Overall Weight | 2.8ton |
|
Dimension
2 cavities
4 cavities |
2800x1700x1800mm 3600x2100x1800mm |
|
PLC—SIEMENS (Germany) |
ELECTRIC VALVE—FESTO (Germany) |
|
CYLINDER—FESTO or AIRTAC (TAIWAN) |
SIGNAL SWITCH—OMRON (Japan) |
Accessories for Blowing Machine
Air Compressor (High & Low Pressure)
Freeze Drier
Filter (High & Low Pressure)
Water Chiller
